MaxiCharger DC V2X

Technical Specifications

DC Output Connection

• Charging mode: CCS1 or CHAdeMO
• Output power: 7/12kW
• Output voltage: CCS1: 150V DC-950V DC, CHAdeMO: 150V DC-500V DC
• Output current: 40A @ 300V
• Number of outputs: 1*CCS1 or 1*CHAdeMO
• Peak efficiency: ≥97%

AC Input Connection

• Earthing system: L1/L2/PE
• Input voltage: 208/240Vac
• Input frequency: 60Hz
• Power factor: ≥0.99
• Harmonic distortion (THDi): ≤5%

General Characteristics

• IP and IK rating: NEMA 4X
• Operating altitude: 6561.7′ (2000m)
• Operating temperature range: -13ºF~+122°F (-25°C~+50°C)
• Storage temperature range: -40ºF~+185°F (-40°C~+85°C)
• Mounting: Wall or floor using a pedestal
• Dimensions (H×W×D): 27.99″x15.19″x6.69″ (711×386×170mm)

User Interface

• Status indication: LED/APP
• Cable length: 16.4′ (5m)
• User interface:
  Autel Charge APP; Autel Charge Cloud
• Connectivity: Bluetooth, Wi-Fi, Ethernet, CAN, RS485
• Communication protocols: OCPP 1.6J (Can be upgraded to OCPP 2.0.1 later)
• User authentication: APP, RFID card
• Software Update: LED/APP

Certification and Standards

• Safety and Compliance: UL2202, CSA C22.2 No.107.1, UL9741, UL 1741:2021, CSA 22.2.107.1:2016, NEC Article 615
• Grid standards: UL 1741 SA/SB:2021, IEEE 1547:2018, IEEE 1547.1:2020, Rule 21, HECO Rule 14; IEEE 1547.1:2022; Interoperability testing; PRD-024-1
• EMC compliance: FCC 15 Class B
• Certification: Energy Star, OpenADR 2.0b
• Warranty: 24 months, warranty extension possible
